Swg 50 Ultra Thin Enameled Copper Wire Magnet Winding Wire For Touch Screen / Sensor

Name: Swg 50 Ultra Thin Enameled Copper Wire Magnet Winding Wire For Touch Screen Sensor
Brand: Rvyuan
Price: 1 USD

Buy cheap Swg 50 Ultra Thin Enameled Copper Wire Magnet Winding Wire For Touch Screen / Sensor product

Brand Name : Rvyuan

Model Number : UEW

Certification : UL/RoHS/ISO

Place of Origin : China

MOQ : Different types with differet MOQ

Price : Negotiation

Payment Terms : Negotiation, T/T, L/C

Supply Ability : Satisfy your demand

Delivery Time : 2-15 workding days

Packaging Details : Spool with carton

Thermal Class : 155

Standards : JIS/IEC/NEMA

Insulation : UEW PEW SEIW EIW

Size Range : 0.020

Color : Nature/Black

Conductor : Copper

Contact Now

SWG 50 ULTRA THIN ENAMELED COPPER WIRE MAGNET WINDING WIRE FOR TOUCH SCREEN SENSOR

Ultra - thin enameled copper winding wire means the diamter that is less than 0.05mm. We are the best and the only one manufacturer in China who can provide ultra -thin enamled copper wire with mass production.Not only can we produce swg 50 ultra thin copper wire, but also thinner, that is 0.012mm.

FEATURE

Ultra thin SWG50
Great quality that is proved by European and Amercian market
Mass production to give you competitive price

Application:

Touch screen/Transformer/ Medical device/Sensor

Swg 50 Ultra Thin Enameled Copper Wire Magnet Winding Wire For Touch Screen / Sensor

Characteristics

Technical requests

Test Results

Conclusion

Sample 1

Sample 2

Sample 3

Surface

Good

Bare Wire Diameter

0.020±

0.02

0.001

Coating Thickness

Overall Diameter

0.022-0.024

0.023

Conductor Resistance

≤60.810Ω/m

56.826

56.474

56.562

Elongation

≥8%

12%

11%

13%

Breakdown Voltage

≥130V

263

247

246

Pinhole Test

≤ 8 holes/5m

Remark:

Test Items

Technical Requests

Results

Conclusion:

Adhesive

Coating layer is good

Approved

Cut-through

170℃ 2mins no breakdown

Heat Shock

155±5℃/30min no crack

Solder Ability

375± 5℃ 2 Sec Smooth

Solvent Resistance

No blister, no expansion, no shed
